| Model | 30XE |
| Round tube/iron tube（S=40kgf/mm2） | Φ30*2.0t |
| Round tube/non-ferrous metal（S=25kgf/mm2） | Φ30*3.5t |
| Round tube/stainless steel（S=60kgf/mm2） | Φ28.6*1.3t |
| Square tube/metal（S=40kgf/mm2） | 25.4*25.4*1.5t |
| Round bar（S=40kgf/mm2） | Φ20 |
| Bending speed | 172°/sec |
| Bending accuracy | ±0.03° |
| Feeding speed | 1000mm/sec |
| Feeding accuracy | ±0.03mm |
| Tube rotate speed | 300°/sec |
| Tube rotate accuracy | ±0.03° |
| Machine head rotation speed | 120°/sec |
| Machine head rotation accuracy | ±0.03° |
| Machine head up and down speed | 220mm/sec |
| Machine head up and down accuracy | ±0.03° |
| Machine head left and right speed | 200mm/sec |
| Machine head left and right accuracy | ±0.03° |
